Pressure-Sensitive Adhesives Transfer Tapes Material Data Sheets

Transfer Tapes with 3M™ Quick Bonding Adhesive 360 provides high bond strength to most surfaces, including many low surface energy plastics such as polypropylene and powder-coated paints. Higher adhesion for a thinner tape with excellent solvent resistance and super-quick stick.

Includes

3M Adhesive Transfer Tape 9626

3M Adhesive Transfer Tape 9627

A pressure-sensitive adhesive (PSA) transfer tape with anisotropic electrical conductivity. Tape 9705 can be applied as die-cut parts or in roll form and has good adhesion to common EMI/RFI substrates such as copper, stainless steel, and smooth gasket materials.

This tape was discontinued by 3M in 2020.

3M™ High-Performance Acrylic Adhesive 200MP is a popular choice, and industry standard, for graphic attachment and general industrial joining applications. It provides outstanding adhesion to metal and high surface energy plastics. This adhesive is initially repositionable for placement accuracy when bonding to plastics. It also performs well after exposure to humidity and hot/cold cycles.

• Up to 400°F (204.4°C) short-term heat resistance
• Excellent solvent resistance
• Excellent shear strength to resist slippage and edge lifting

Available in 2.3 mil (0.06 mm) and 5.2 mil (0.13 mm) adhesive thickness and with single and double liners.

Adhesive transfer tapes in this series include:

467MP • 468MP • 467MPF • 468MPF • 7952MP • 7955MP • 7962MP • 7965MP • 9172MP • 9185MP • 9667MP • 9668MP

3M™ Adhesive Transfer Tapes that use 3M 300MP acrylic adhesive are suitable for bonding to most surfaces. The adhesive provides an excellent bond to fabricated foams, fabrics, and low surface energy (LSE) substrates and has good shear strength at elevated temperatures.

These tapes have excellent UV and humidity resistance and perform well at temperatures up to 250°F (121°C).

9772WL, 9773WL, 9774WL, 9774FL and 9775WL

3M™ Adhesive Transfer Tapes with 3M™ Low Surface Energy Acrylic Adhesive 300LSE provides high bond strength to most surfaces, including many low surface energy (LSE) plastics such as polypropylene and powder-coated paints. The solvent-free acrylic adhesive also provides excellent adhesion to surfaces lightly-contaminated with oil and is typically used with machine parts.

• Usable for short periods (minutes, hours) at temperatures up to 300°F (148°C) and for intermittent longer periods (days, weeks) up to 200°F (93°C).
• Lower Service Temperature: -40°F (-40°C)
• Excellent humidity, water, and solvent resistance

Available in 2.3 mils (0.06 mm) and 5.2 mils (0.13 mm) adhesive thickness and with single and double liners.

Adhesive transfer tapes in this series include:

8132LE • 8153LE • 9453LE • 9471LE • 9472LE • 9653LE • 9671LE • 9672LE

3M Low Fogging Adhesive Transfer Tapes are pressure-sensitive transfer tapes made with 3M 300MP acrylic adhesive and specially formulated to be low fogging with good adhesion to most common low surface energy (LSE) materials. These tapes are ideal for use in automotive interior applications.

• Temperature Resistance: Short term: 250°F (121°C).
• Meets typical OEM fogging requirements
• Excellent humidity, water, and solvent resistance

Available in 4.2 mils (0.107 mm), 5 mils (0.127 mm), 6.2 mils (0.157 mm), and 8 mils (0.203 mm) adhesive thickness.

Adhesive transfer tapes in this series include:

6035PC • 6035PL • 6038PC • 6038PL

3M™ Ultra High-Temperature 100HT Adhesive Transfer Tapes feature a high-performance and low-outgassing adhesive system with excellent high-heat resistance. Adhesion strength is significantly higher than typical pressure-sensitive tapes.

3M™ Ultra High-Temperature 100HT Adhesive Transfer Tapes 9082UV and 9085UV have a UV fluoresce agent enabling black light inspection during converting and assembly.

Typical application examples are automotive under-hood, printed circuit boards, and heat sink bonding in electronics applications subjected to high solder reflow temperatures.

• Usable for short periods (minutes, hours) at temperatures up to 540°F (280°C) and for intermittent longer periods (days, weeks) up to 350°F (177°C).
• Lower Service Temperature: -40°F (-40°C)

Available in 2 mil (0.05 mm) and 5 mil (0.13 mm) adhesive thickness and with either a white printed paper or brown paper liner.

Adhesive transfer tapes in this series include:

9082 • 9085 • 9082UV • 9085UV

3M Adhesive Transfer Tapes with 3M Adhesive 350 have a modified acrylic adhesive with a very high bond strength to many different surfaces. These tapes are offered with a fiber-reinforced adhesive which is essential for roll stability in narrow slit widths.

This adhesive is a good choice for applications that require adhesion to Low Surface Energy (LSE) plastics, powder coatings, and oily metals.

• Usable for short periods (minutes, hours) at temperatures up to 450°F (232°C) and for intermittent longer periods (days, weeks) up to 300°F (149°C).
• Lower Service Temperature: -40°F (-40°C)
• Excellent chemical resistance and high strength, even at elevated temperatures.

Available in 2 mils (0.05 mm) and 5 mils (0.127 mm) adhesive thickness and either a densified kraft or poly-coated kraft liner.

Adhesive transfer tapes in this series include:

9442 • 9445 • 9482PC • 9485PC • 9485EK • 9675

These 3M VHB Adhesive Transfer Tapes utilize 3M™ High-Performance Acrylic Adhesive 100MP, which has excellent long-term holding power with much higher adhesion strength than typical pressure-sensitive adhesive systems.

These 3M VHB Adhesive Transfer Tapes are transparent. They are ideal for many inside and outside industrial applications and can replace rivets, spot welds, liquid adhesives, and other permanent mechanical fasteners.

• Usable for short periods (minutes, hours) at temperatures up to 500°F (260°C) and for intermittent longer periods (days, weeks) up to 300°F (149°C).
• The ideal tape application temperature range is 70°F to 100°F (21°C to 38°C).
• Excellent chemical and UV resistance and high strength, even at elevated temperatures.

Available in 2 mils (0.05 mm), 5 mils (0.127 mm), and 10 mils (0.26 mm) adhesive thickness with a 58# poly-coated kraft paper liner.

Adhesive transfer tapes in this series include:

F9460PC • F9469PC • F9473PC
